TRACO POWER TME1212S isolated DC/DC converter
The TME series consists of ultra-compact, 1-watt isolated DC/DC converters in a SIP package, requiring only 0.7 cm² of board space. They offer efficient power conversion up to 80%, with input-to-output isolation of 1000 VDC, suitable for space-constrained electronic designs. Operating across -40°C to +85°C, they feature industry-standard pinouts, full SMD design, and extensive testing for high reliability. These converters are ideal for generating isolated voltages in industrial, automation, and electronic systems, with a 3-year warranty ensuring durability and performance.
TRACO POWER TME1212S isolated DC/DC converter Specifications:
- Input Voltage Range: 3.3 VDC, 5 VDC, 12 VDC, 24 VDC
- Output Voltage Options: 3.3 V, 5 V, 9 V, 12 V, 15 V
- Max Output Current: 80 mA to 260 mA depending on model
- Efficiency: Up to 80%
- Isolation Voltage: 1000 VDC
- Operating Temperature Range: -40°C to +85°C
- Ripple and Noise: 150 mV pk-pk at 20 MHz bandwidth
- Short Circuit Protection: Limited 1 second
- Surge Voltage Max: 6 V to 30 V depending on model
- External Capacitor: 13.3 pF recommended to reduce ripple
- Reliability: MTTF over 2 million hours
- Case Material: Non-conductive black UL 94-V0 rated plastic
- Pinout: Industry standard, suitable for SMD mounting
- Soldering Temperature: Max 265°C for 10 seconds
Buy the Buy Traco Power TME Series DC/DC Converter Part Number TME1212S Online
Purchase the Traco Power TME1212S isolated DC/DC converter online today and benefit from its compact size, high efficiency up to 80%, 1000 VDC isolation, and wide operating temperature range. Perfect for space-constrained industrial and automation applications, this 1-watt converter offers superior reliability, industry-standard pinouts, and extensive testing, ensuring a durable and dependable power supply solution. Upgrade your electronic systems with this cutting-edge, high-quality component and enjoy quick delivery and expert support.
Order your Traco Power TME1212S series 1 watt isolated DC/DC converter today and ensure reliable, space-saving power conversion for your electronic projects.
Frequently Asked Questions
Where can I buy TRACO POWER TME1212S?
You can click on the BUY or RFQ button to purchase TME1212S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TME1212S?
You can download the TME1212S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TME1212S?
TRACO POWER
