TRACO POWER THN202423 DC/DC Converter
The THN 20-2423 is a high-performance, board-mount DC/DC converter with a shielded metal case and an isolated base plate. It provides two output channels delivering a total of 20W of power. The converter operates within an input voltage range of 18 to 36V DC and offers a regulated ±15V DC output. It features a wide 2:1 input voltage range, high efficiency of approximately 90%, and an isolation voltage of 1500V DC between input and output. The device requires no minimum load and includes adjustable output voltages, remote ON/OFF control, and is capable of functioning reliably at temperatures up to 75°C or 85°C with an optional heat sink. Its compact design makes it ideal for applications where space is limited, including power management, industrial systems, sensing and instrumentation, and communication/networking equipment.
TRACO POWER THN202423 DC/DC Converter Specifications:
- Input voltage range: 18-36V DC
- Output voltage: ±15V DC
- Output current max.: 1,330 mA
- Efficiency: up to 90%
- Isolation voltage: 1500 VDC
- Operating temperature: -40°C to +75°C, up to 85°C with heat sink
- Dimensions: 1.0 x 1.0 x 0.4 inches
- Weight: 15 g
- Slew rate: 330 kHz
- Start-up voltage: 36 VDC
- Over voltage protection: 16.8-20.5 V
- Ripple and noise: 100 mVp-p with external capacitor
- Short circuit protection: automatic recovery
- Remote ON/OFF: 3.0 - 15 VDC or open circuit
- Soldering temperature: Max. 265°C / 10 sec
- Environmental compliance: RoHS and Reach compliant
- Certifications: UL 60950-1, EN 60950-1, IEC 60950-1
Buy the Traco Power THN-20-2423 – Reliable DC-DC Converter for Industrial Applications
Purchase the Traco Power THN-20-2423 online today to benefit from advanced high-efficiency power conversion. With its robust design, isolated output, and wide voltage ranges, this 20W converter ensures reliable performance in industrial environments. Its compact size and optional heat sink facilitate installation in space-constrained applications such as instrumentation, communication systems, and industrial automation. Enjoy fast delivery and excellent customer service while ensuring your system's power regulation is precise, stable, and safeguarded against voltage fluctuations and surges. Upgrade your power solutions now for enhanced performance and dependability.
Buy Traco Power THN-20-2423 now and experience unmatched reliability and high efficiency for your industrial power management needs.
Frequently Asked Questions
Where can I buy TRACO POWER THN202423?
You can click on the BUY or RFQ button to purchase THN202423 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN202423?
You can download the THN202423 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN202423?
TRACO POWER
