TRACO POWER THI32423 Medical Grade DC/DC Converter
This compact 3 Watt DC/DC converter from the ThI 3 Series offers reinforced insulation and high isolation voltage, making it ideal for medical and industrial applications. It features a fully regulated output, low leakage current, and short circuit protection. Encapsulated in a DIP-24 package, it complies with safety standards such as IEC/EN 60601-1 and IEC/EN 60950-1. Operating temperature ranges from -40°C to +75°C, with excellent EMI filtering, making it perfect for medical instrumentation and control systems requiring certified insulation and reliable performance.
TRACO POWER THI32423 Medical Grade DC/DC Converter Specifications:
- Input Voltage Range: 5 VDC, 12 VDC, 24 VDC
- Output Voltage: 5 V, 12 V, 15 V, 24 V (single or dual output models)
- Output Current Max: 600 mA (5 V), 250 mA (12 V), 200 mA (15 and 24 V)
- Efficiency: up to 64%
- Isolation Voltage: 4000 VACrms, rated for 300 Vrms working
- Isolation Capacitance Input/Output: 20 pF typ.
- Leakage Current: 2 pA at 240VAC, 60Hz
- Operating Temperature Range: -40°C to +75°C
- Humidity: 95% rel. H max.
- Switching Frequency: 25 - 60 kHz
- Protection: Short circuit, automatic recovery
- Dimensions: Encapsulated DIP-24 package, weight approx. 12.4 g
- Compliance: IEC/EN 60601-1, IEC/EN 60950-1, RoHS
- Temperature Coefficient: +0.02 %/K
Buy the Traco Power Series THI 3 DC/DC: THI32423
Order the Traco Power THI32423 today, a 3 Watt medical-grade DC/DC converter designed for healthcare devices and industrial controls. Featuring reinforced insulation, high isolation voltage of 4000 VACrms, and compliance with IEC 60601-1 safety standards, it offers reliable and safe power conversion. With low leakage current, short circuit protection, and a wide operating temperature range from -40°C to +75°C, this converter ensures optimal performance in demanding environments. Its compact DIP-24 encapsulation makes integration straightforward, supporting applications requiring certified insulation and dependable operation.
Get Traco Power THI32423 today—built for medical reliability and industrial durability.
Frequently Asked Questions
Where can I buy TRACO POWER THI32423?
You can click on the BUY or RFQ button to purchase THI32423 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THI32423?
You can download the THI32423 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THI32423?
TRACO POWER
