TRACO POWER THL101211 DC/DC Converter
The THL 10 series from TracoPower consists of 10W DC/DC converters designed for general-purpose applications. These compact converters are housed in a 1" x 1" metal case with an industrial standard pinout, offering a wide 2:1 input voltage range, and an input filter meeting EN 55022 Class A without external components. They feature short circuit and overvoltage protection, operate in a temperature range of -40°C to +80°C (up to +85°C with heatsink), and are suitable for instrumentation, communication, and industrial electronics. Options include multiple output voltages and current capacities, with efficiencies up to 89%, 1500VDC I/O isolation, low ripple, and robust safety standards compliance.
TRACO POWER THL101211 DC/DC Converter Specifications:
- Input Voltage Range: 12 VDC (nominal), surge up to 25 V max.
- Output Voltage: 12 VDC, max current 830 mA.
- Efficiency: 87%.
- Input Current at Full Load: 1000 mA at 12 V input.
- Isolation Voltage: 1500 VDC (60 sec).
- Isolation Capacitance: 2000 pF max.
- Operating Temperature Range: -40°C to +80°C (up to +85°C with heatsink).
- Ripple and Noise: approximately 80 mVp-p.
- Switching Frequency: approximately 300 kHz.
- Physical Case Material: Metal with epoxy potting, weight approx. 15 g.
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1.
Buy the TracoPower THL 101211 – Reliable DC/DC Converter for Industrial Applications
Purchase the TracoPower THL 101211 DC/DC converter online today to ensure your industrial, instrumentation, or communication projects benefit from high efficiency, reliable isolation, and compact design. With a 1" x 1" metal case, wide input voltage range, and low ripple, this converter is ideal for demanding environments. Enjoy quick online ordering and fast delivery, backed by a 3-year warranty, making it a smart choice for both replacement and new applications in industrial electronics and distributed power systems.
Order your TracoPower Series THL 101211 12VDC 10W converter today and give your industrial projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy TRACO POWER THL101211?
You can click on the BUY or RFQ button to purchase THL101211 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL101211?
You can download the THL101211 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL101211?
TRACO POWER
