TRACO POWER TMP30124 power supply module
The TMP30124 power supply module is a fully encapsulated AC/DC power module designed for space-critical industrial and commercial applications. It features a robust plastic casing, universal input voltage 85-264 VAC, 60 W output power, and high efficiency of 84%. The device provides multiple outputs, including 24 VDC at 1250 mA, with built-in protections such as over-temperature, short circuit, overload, and overvoltage safeguards. Its reliability is backed by an MTBF exceeding 280,000 hours, making it suitable for dusty, polluted environments, and standard safety approvals including IEC/EN/UL 60950-1.
TRACO POWER TMP30124 power supply module Specifications:
- Input Voltage: 85-264 VAC, 47-440 Hz
- Output Power: 60 W
- Output Voltage: 24 VDC
- Output Current: 1250 mA
- Efficiency: 84%
- Isolation Voltage: 3000 VAC
- Operating Temperature Range: -25°C to +70°C (with derating above +50°C)
- Protection: Over-temperature, short circuit, overload, overvoltage
- Outer Dimensions: Approx. 138 mm x 50 mm x 25 mm
- Mounting: PCB/Chassis mount via screw terminal or optional DIN-rail adaptor
- Certifications: IEC/EN/UL 60950-1, CB report, UL approvals
- Housing Material: UL 94V-0 rated plastic resin
Buy the Buy Traco Power TMP30124 Part Number TMP30124 Online
Order the Traco Power TMP30124 power supply module online now for reliable performance in industrial environments. Featuring 60W output, universal 85-264 VAC input, and advanced protections including over-temperature, short circuit, and overload safeguards, this fully encapsulated device guarantees durability in dusty, polluted conditions. Its compact design includes versatile mounting options like PCB, chassis, and DIN-rail, making installation flexible. With UL and IEC standards certification and an MTBF exceeding 280,000 hours, it’s perfect for demanding electronic and industrial control applications.
Get Traco Power TMP30124 today—built for industrial reliability with high efficiency and comprehensive protections.
Frequently Asked Questions
Where can I buy TRACO POWER TMP30124?
You can click on the BUY or RFQ button to purchase TMP30124 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMP30124?
You can download the TMP30124 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMP30124?
TRACO POWER
