TRACO POWER THL202410WI DC/DC Converter Module
The THL 20WI series from Traco Power consists of 20W high-density DC/DC converters in a compact 1.0 inch x 1.0 inch x 0.4 inch metal case. These modules feature an ultra-wide 4:1 input voltage range, various regulated output voltages including 3.3VDC, 5VDC, 12VDC, 15VDC, and 24VDC, with currents up to 4A. They include remote on/off, 1500VDC I/O isolation, low ripple, and noise. Operating from -40°C to +75°C (+85°C with heatsink), they are ideal for space-constrained applications in communication, industrial electronics, and instrumentation. Compliance includes UL, IEC, and CSA safety standards, with high efficiency up to 90% and durable, RoHS-compliant design for reliable performance over long service life. The series is suitable for mobile equipment, distributed power systems, and applications demanding high power density and efficiency.
TRACO POWER THL202410WI DC/DC Converter Module Specifications:
- Power Output: 20W
- Input Voltage Range: 4:1 wide input, nominal 24VDC or 48VDC variants
- Output Voltages: 3.3V, 5V, 12V, 15V, 24V, ±12V, ±15V
- Maximum Output Current: up to 4A
- Efficiency: up to 90%
- Dimensions: 1.0” x 1.0” x 0.4” (25.4mm x 25.4mm x 10.2mm)
- Isolation Voltage: 1500 VDC
- Isolation Resistance: >1000 MΩ
- Capacitance: 1500 pF
- Operating Temperature: -40°C to +75°C, up to +85°C with heatsink
- Ripple & Noise: 75–150 mVp-p depending on output voltage
- Switching Frequency: approx. 330 kHz
- Protection: Short circuit, automatic recovery
- Soldering Temperature: 260°C / 10 sec. max.
- Safety Standards: UL/cUL 60950-1, IEC 60950-1, CSA
Buy the Traco Series THL DC/DC: THL202410WI
Purchase the Traco Power THL series 20W DC/DC converter online today and enjoy reliable, high-performance power solutions for industrial control, communication, and instrumentation applications. With ultra-wide input voltage ranges, excellent efficiency up to 90%, and compact size, these modules are ideal for space-constrained environments. They feature remote on/off, high isolation voltage, low ripple and noise, and are compliant with safety standards including UL and IEC. Ensure industrial electronics and communication systems operate smoothly with this durable, RoHS-compliant power converter.
Get Traco Series THL202410WI today—compact, high-efficiency power supply built for reliable performance in space-constrained applications.
Frequently Asked Questions
Where can I buy TRACO POWER THL202410WI?
You can click on the BUY or RFQ button to purchase THL202410WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL202410WI?
You can download the THL202410WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL202410WI?
TRACO POWER
