TRACO POWER TMA0512S DC/DC Converter
The TMA series are compact, high-efficiency 1 Watt isolated DC/DC converters in a Single-in-Line package, ideal for space-critical applications requiring board-level power distribution. Featuring industry-standard pinouts, optional single or dual outputs, and an unregulated design, these devices deliver up to 81% efficiency and operate reliably within a temperature range of -40°C to +85°C. The converters are RoHS compliant, lead-free, and undergo 100% burn-in testing, ensuring durability and consistent performance in various industrial and electronic applications.
TRACO POWER TMA0512S DC/DC Converter Specifications:
- Power Rating: 1 Watt
- Input Voltage Range: 5 VDC, 12 VDC, 15 VDC, 24 VDC
- Output Voltages: 5 VDC, 10 VDC, 12 VDC, 15 VDC
- Output Currents: up to 200 mA depending on model
- Efficiency: Up to 81%
- Isolation Voltage: 1000 VDC
- Operating Temperature: -40°C to +85°C
- Case Material: Non-conductive black plastic (UL 94V-0 rated)
- Package Weight: 2.2g to 2.6g depending on model
- Soldering Temperature: Max 260°C / 10 s
- Dimensions: Approx. 19.5 mm x 9.0 mm x 12.5 mm
- Switching Frequency: 70 to 120 kHz
- Humidity: Up to 95% relative humidity (non-condensing)
- Isolation Resistance: >1,000 MOhm
- Insulation Capacitance: 60-100 pF
Buy the Buy TRACOPOWER Power TMA Series DC/DC Converter Part Number TMA0512S Online
Experience reliable and compact power conversion with the TRACOPOWER TMA0512S DC/DC converter. Designed for demanding applications, it provides up to 81% efficiency, excellent thermal stability, and 1000 VDC isolation. Its small SIP package allows easy integration in space-constrained environments, making it ideal for various industrial, medical, and electronic projects. Featuring RoHS compliance and rigorous burn-in testing, this converter guarantees durability and consistent performance. Purchase online today for fast delivery and trusted quality that ensures your projects operate smoothly and efficiently.
Order your TRACOPOWER TMA0512S series high-efficiency 1W DC/DC converter today and ensure reliable power isolation for your space-critical projects.
Frequently Asked Questions
Where can I buy TRACO POWER TMA0512S?
You can click on the BUY or RFQ button to purchase TMA0512S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMA0512S?
You can download the TMA0512S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMA0512S?
TRACO POWER
