TRACO POWER TMDC062412 Industrial DC/DC converter
The TMDC 06 Series is a 6 Watt, fully encapsulated industrial DC/DC converter designed for harsh environments. It features an ultra-wide 4:1 input voltage range (9-36 V or 18-75 V), high efficiency up to 85%, and reinforced EMC immunity (EN 55035). Its compact plastic enclosure (2.09 x 1.34 x 1.04 inches) offers robust insulation (3000 VDC), operating temperature from -40°C to +80°C without derating, and includes protective functions like overload, short circuit, and undervoltage protection. Suitable for industrial automation, control systems, and power distribution applications requiring reliable isolation and EMC compliance.
TRACO POWER TMDC062412 Industrial DC/DC converter Specifications:
- Input Voltage Range: 9-36 VDC or 18-75 VDC with ultra-wide 4:1 ratio
- Output Power: 6 Watts
- Efficiency: Up to 85%
- Isolation Voltage: 3000 VDC
- Operating Temperature: -40°C to +80°C without derating
- Dimensions: 2.09 x 1.34 x 1.04 inches (53.0 x 33.8 x 26.5 mm)
- Protection: Overload, undervoltage, short circuit; DC-OK LED and remote on/off
- EMC Compliance: EN 55032 class A, EN 55035
- Certifications: UL 62368-1, IEC 62368-1
- Housing Material: UL 94V-0 rated plastic with screw terminal connections
- Cooling: Natural convection, ambient up to 105°C
- Switcher Frequency: 370 kHz typ.
- Remote Control: Voltage controlled remote on/off
- Derating: 4% per K above 80°C
Buy the Buy Traco Power DC/DC Converter Series TMDC06 Part Number TMDC062412 Online
Secure your supply of reliable power with the Traco Power industrial DC/DC converter TMDC 06 series. It offers wide input voltage options, high efficiency up to 85%, and strong EMC immunity, making it perfect for demanding industrial applications. Its compact plastic enclosure ensures durability and ease of installation, while the comprehensive protection features safeguard your systems. Trust in UL and IEC safety certifications for peace of mind. Purchase online today to integrate this robust, fully encapsulated converter into your power management solutions with confidence.
Order your Traco Power Series TMDC062412 6W industrial DC/DC converter today and ensure reliable, efficient power in harsh industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TMDC062412?
You can click on the BUY or RFQ button to purchase TMDC062412 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMDC062412?
You can download the TMDC062412 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMDC062412?
TRACO POWER
