TRACO POWER TMR94822 DC-DC Converter
The TMR 9-4822 from Tracopower is a high-power density, 9W DC-DC converter featuring fully regulated and isolated dual outputs within an 8-pin SIP package. It supports an input voltage range from 36VDC to 75VDC, with an input current of only 5mA at no load. The converter provides dual outputs of ±12VDC with a maximum current of ±375mA each. It operates at a switching frequency of 500kHz with an efficiency of 87%, and can withstand a maximum surge voltage of 100V. The compact dimensions are 9.6mm x 11.2mm x 21.8mm, making it suitable for space-critical applications in communication and instrumentation equipment. The device includes features such as remote on/off control, indefinite short circuit protection, and no minimum load requirement. It offers an input to output isolation voltage of 1500VDC for 60 seconds, with an isolation resistance greater than 1 GΩ and maximum capacitance of 50pF. The converter meets EN 55022 Class A emissions standards and complies with UL 60950-1 and IEC/EN 60950-1 safety standards. It also features robust electrostatic discharge protection conforming to EN 61000-4-2. Operating temperature ranges from -40°C to 85°C, with UL and IEC safety approvals.
TRACO POWER TMR94822 DC-DC Converter Specifications:
- Input Voltage Range: 36VDC to 75VDC
- Input Current at No Load: 5mA
- Surge Voltage: 100V max (1 sec.)
- Output Voltage: ±12VDC
- Output Current Max: 375mA per rail
- Efficiency: 87%
- Switching Frequency: 500kHz
- Isolation Voltage: 1500VDC for 60 sec.
- Isolation Resistance: >1 GΩ
- Maximum Capacitance: 50pF
- Operating Temperature: -40°C to +85°C
- Size: 9.6mm x 11.2mm x 21.8mm
- RoHS, UL 60950-1, IEC/EN 60950-1 compliant
- Electrostatic Discharge: EN 61000-4-2
- Input to Output Isolation Capacitance: 50pF
Buy the Buy Tracopower TMR 9-4822 DC-DC Converter Part Number TMR94822 Online
Purchase the Tracopower TMR 9-4822 today online for a reliable, compact 9W DC-DC converter designed for communication, instrumentation, and industrial electronics. Its dual ±12VDC outputs deliver up to 375mA each, with 87% efficiency and wide temperature operation from -40°C to +85°C. Features include remote on/off control, short circuit protection, and high isolation voltage of 1500VDC. The ultra-compact dimensions (9.6mm x 11.2mm x 21.8mm) make it ideal for space-critical applications. Enjoy fast delivery and trusted quality with our online purchasing options.
Get Tracopower TMR 9-4822 today—high-efficiency, dual output DC-DC converter with remote On/Off for demanding electronic applications.
