TRACO POWER TSRN12450 DC/DC Regulator Module
The TSRN-1 series are high-efficiency DC/DC switching regulators designed for industrial applications. These drop-in replacements for linear regulators operate up to 95% efficiency, with a wide input range up to 42 VDC and output voltages from 1.5 VDC to 15 VDC. They feature built-in filters, over-temperature, and short circuit protections, no heatsink needed, operate from -40°C to +85°C, and are ideal for energy-sensitive environments. Suitable for positive and negative output circuits, they provide stable regulation, low standby current, and high reliability with a 3-year warranty.
TRACO POWER TSRN12450 DC/DC Regulator Module Specifications:
- Input Voltage Range: 4.6-42 VDC (positive models), 4.6-32 VDC (negative models)
- Output Voltage: 1.5 VDC to 15 VDC depending on model
- Output Current: Up to 10A
- Efficiency: Max 95%
- Operation Temperature: -40°C to +85°C
- Ripple and Noise: 50-75 mVpk-pk
- Input Ripple Current: 100 mA typ.
- Short Circuit Protection: Yes, automatic recovery
- Over-temperature Protection: Yes at +170°C
- Switching Frequency: 300-580 kHz depending on model
- Dimensions: Casings are non-conductive plastic; weight approximately 1.9g
- Soldering Profile: Max +265°C / 10 sec.
- Certifications: Reach, RoHS compliant
Buy the TRACOC Power TSRN-1 – Reliable DC/DC Regulators for Industrial Applications
Enhance your industrial power management with the high-efficiency DC/DC regulator module from Traco Power. Designed for reliable performance, it offers up to 95% efficiency, wide input voltage compatibility, built-in protections, and no external heatsink required. Perfect for energy-sensitive projects, it ensures stable output, low standby current, and excellent line/load regulation. With versatile positive and negative output options, the TSRN-1 series guarantees long-term durability, safety, and ease of integration. Purchase online now for optimal power solution performance.
Get TRACOC Power TSRN12450 today—built for precision, high efficiency, and long-lasting durability in demanding industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TSRN12450?
You can click on the BUY or RFQ button to purchase TSRN12450 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TSRN12450?
You can download the TSRN12450 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TSRN12450?
TRACO POWER
