TRACO POWER TMR2412 DC/DC Converter Module
The TMR-2 series offers compact, high-efficiency 2W isolated DC/DC converter modules with wide 2:1 input voltage range, regulated output, and remote On/Off control. Suitable for space-constrained applications such as communication, instrumentation, and industrial electronics, these converters operate from -40°C to +85°C, feature continuous short-circuit protection, and come in a SIP-8 package occupying only 2.0 cm2. They are UL60950-1 and RoHS compliant, ensuring safety and environmental standards are met, with a 3-year product warranty for reliability.
TRACO POWER TMR2412 DC/DC Converter Module Specifications:
- Input Voltage Range: 4.5 - 9.0 VDC / 9-18 VDC / 18 - 36 VDC / 36-75 VDC
- Output Voltage: 12 VDC (nominal) / +5 VDC / +12 VDC / +15 VDC
- Maximum Output Current: 165 mA to 500 mA depending on model
- Efficiency: up to 84%
- Isolation Voltage: 1600 VDC
- Operating Temperature Range: -40°C to +85°C
- Humidity: 5-95% rel. H non-condensing
- Dimensions: 21.8 mm (0.86 in.) length; non-conductive UL 94V-0-rated plastic case
- Weight: 48 g
- Surge Voltage (max.): 15 V to 100 V depending on input
- Switching Frequency: 100 to 650 kHz
- Protections: Short circuit (automatic recovery), overvoltage, and thermal shutdown
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, RoHS compliant
Buy the Traco Power Series TMR2 DC/DC Converter: TMR2412
Purchase the Traco Power TMR2412 DC/DC converter online today to benefit from high efficiency, compact size, excellent load regulation, and Safety standards compliance. Perfect for space-critical applications in industrial, communication, and instrumentation sectors, this module provides regulated 12 V output, wide input voltage range, remote On/Off, and full short-circuit protection. With a 3-year warranty and RoHS compliance, this reliable power solution ensures robust performance in demanding environments. Secure your supply today with our easy online ordering and fast delivery options, ensuring your project runs smoothly and efficiently.
Buy Traco Power TMR2412 converter now and experience unmatched reliability, efficiency, and space-saving design for industrial and communication electronics.
Frequently Asked Questions
Where can I buy TRACO POWER TMR2412?
You can click on the BUY or RFQ button to purchase TMR2412 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR2412?
You can download the TMR2412 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR2412?
TRACO POWER
