XP POWER ECE80DINCLIP AC-DC Power Module
The ECE80 Series AC-DC power supplies offer 80 Watts of power with ultra-compact design, suitable for PCB, chassis mount, and DIN rail applications. They feature high efficiency, low no-load power consumption, and operate from -40°C to +70°C. With output voltages from 12 to 48 VDC, peak load capabilities of up to 130%, and compliance with safety and EMC standards, these modules are reliable for industrial and automation systems. Their durable construction supports continuous operation in harsh environments with a wide input voltage range and high power density.
XP POWER ECE80DINCLIP AC-DC Power Module Specifications:
- Input Voltage Range: 85-264 VAC, derates at 90 VAC to 90% load, at 85 VAC to 85% load
- Output Power: 80W
- Output Voltage: 12V, 15V, 24V, 36V, 48V
- Output Current: 6.67A, 5.33A, 3.33A, 2.2A, 1.67A respectively
- Peak Load Capability: Up to 130% for 30 seconds
- Efficiency: 86-88%
- Operating Temperature Range: -40°C to +70°C, derating above +50°C
- Dimensions (PCB version): 3.60 x 1.80 x 1.10 inches
- Dimensions (Chassis version): 4.45 x 1.87 x 1.12 inches
- Power Density: >11 W/in³
- No Load Power Consumption: <0.3 W
- Protection: Overvoltage, overload, short circuit, over-temperature
- Isolation Voltage: 3000 V (input to output)
- Compliance: UL, cUL, EN55022, EN61000-4
- Cooling: Convection cooled
- Mounting Options: PCB, chassis with screw terminals, DIN rail
Buy the Buy XP Power ECE80 Series Power Supply Part Number ECE80DINCLIP Online
Purchase the XP Power ECE80 Series AC-DC power supply online today—this compact and efficient module delivers 80 Watts with a wide input voltage range, suitable for industrial and automation applications. Its robust construction supports operation from -40°C to +70°C, with peak load capability of up to 130%. Easy to install with PCB, chassis, and DIN rail options, ensuring reliable power conversion. Experience high efficiency, low no-load power consumption, and compliance with safety standards. Perfect for reliable, continuous operation in demanding environments.
Get XP Power ECE80 Series power supply today—designed for industrial reliability, high efficiency, and easy DIN rail mounting.
Frequently Asked Questions
Where can I buy XP POWER ECE80DINCLIP?
You can click on the BUY or RFQ button to purchase ECE80DINCLIP from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ECE80DINCLIP?
You can download the ECE80DINCLIP datasheet or visit the XP POWER website for support.
Who is the manufacturer of ECE80DINCLIP?
XP POWER
