XP POWER EML30US05E Medical Power Supply
The EML30 series comprises compact, versatile open frame and encapsulated AC-DC power supplies engineered for medical and industrial systems. They feature multiple mechanical options, including PCB, open frame, chassis, and DIN rail mounts, ensuring easy integration. These supplies meet global medical safety standards, comply with Class B emission regulations, and provide a 130% peak load capacity for 30 seconds. With output voltages from 3.3V to 48V and Class II isolation, they are ideal for healthcare, instrumentation, sensing, and automation applications requiring reliable, high-performance power solutions.
XP POWER EML30US05E Medical Power Supply Specifications:
- Input Voltage Range: 85-264 VAC
- Input Frequency: 47-63 Hz
- Efficiency: 79-88%
- Operating Temperature: -20°C to +70°C, derating linearly from 100% at 50°C to 50% at 70°C
- Output Voltages: 3.3V, 5V, 9V, 12V, 15V, 24V, 36V, 48V
- Output Power: 30 Watts
- Peak Load Capability: 130% for 30 seconds
- Isolation: Class II, 000 VAC input-to-output
- Dimensions: Ranging from 2.96 x 1.36 x 1.05 inches to 3.78 x 1.57 x 1.12 inches depending on mount style
- Mounting Options: PCB, open frame, chassis, DIN rail, screw terminals
- Certifications: Medical safety standards, UL, IEC60601-1, EN60601-1-2, CE, UKCA
- Compliance: Emission and immunity standards including EN55032/11 Class B, EN61000-4
Buy the XP Power EML3O – Reliable Medical Power Supplies for Industrial Applications
Enhance your healthcare and industrial projects with the XP Power EML30 series, offering compact, reliable power with versatile mounting options. These power supplies are designed to meet stringent medical safety standards, ensuring safe and efficient operation across various applications. With output voltages from 3.3V to 48V and a peak load capability of 130% for 30 seconds, they deliver consistent power even under peak demands. Easy to install via PCB, chassis, or DIN rail mounts, they enable seamless integration into your systems, guaranteeing high performance, safety, and compliance with global standards for medical and industrial use.
Order your XP Power SeriesEML30E encapsulated power supply today and give your healthcare and industrial systems the dependable power they deserve.
