XP POWER EML30US36S Medical Power Supply
The EML30 series comprises open frame and encapsulated AC-DC power supplies with a single output, designed specifically for medical applications. They offer versatile mechanical options, including PCB mount, open frame, chassis mount with screw terminals, and DIN rail mounting. These power supplies are compliant with global medical safety standards, feature Class B emissions for conducted and radiated noise, and support a peak load of 130% for 30 seconds. Its compact size, Class II isolation, and wide input voltage range make it ideal for healthcare devices, sensing, and instrumentation systems, ensuring reliable power delivery in critical environments.
XP POWER EML30US36S Medical Power Supply Specifications:
- Input Voltage Range: 85-264 VAC
- Input Frequency: 47-63 Hz
- Input Power (No Load): 0.3 W
- Efficiency: 79-88%
- Operating Temperature: -20°C to +70°C
- Isolation: Input to Output 4000 VAC
- Output Voltage: 36 VDC
- Output Power: 30 W
- Output Current: 0.83 A
- Mechanical Dimensions (Typical): 3.78 x 1.57 x 1.12 inches
- Switching Frequency: 70 kHz
- Weight: 0.37 lbs
- Overvoltage Protection: 115-140% Vnom
- Overload Protection: 120-185%
- Short Circuit Protection: Trip & Restart (hiccup mode)
- Vibration & Shock: Complies with IEC standards
- Certifications: EN60601-1, ANSI/AAMI ES60601-1, UL, CSA
- Cooling Method: Convection cooled
- Humidity: Up to 95% RH non-condensing
- Altitude: Up to 3048 meters
Buy the Velo EML30US36S – Reliable Medical Power Supply for Healthcare Devices
Enhance your healthcare device design with the reliable Velo power supply. The EML30US36S offers versatile mounting options, Class II safety, and peak load support for critical medical applications. Its compact size ensures easy integration into modern sensing, instrumentation, and medical equipment, providing consistent power with high efficiency and safety compliance. Order online today and benefit from fast delivery, competitive pricing, and dedicated customer support for your medical power needs.
Buy Velo EML30US36S now and experience unmatched reliability and performance in medical applications.
Frequently Asked Questions
Where can I buy XP POWER EML30US36S?
You can click on the BUY or RFQ button to purchase EML30US36S from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part EML30US36S?
You can download the EML30US36S datasheet or visit the XP POWER website for support.
Who is the manufacturer of EML30US36S?
XP POWER
