XP POWER ITP0324D12 Industrial Power Module
The ITP series is a compact 3W DC-DC converter module designed for reliable industrial applications. It features regulated single and dual outputs from 3.3V to 15V DC, with a wide 4:1 input voltage range from 4.5V to 75V. Encased in a robust SIP6 package, it offers high efficiency, 1.6kVDC input/output isolation, and operates across temperatures from -40°C to +75°C. The module includes short-circuit protection, remote On/Off controls for single outputs, and is compliant with EN55032 standards, making it suitable for demanding industrial environments.
XP POWER ITP0324D12 Industrial Power Module Specifications:
- Power: 3 Watts
- Input Voltage Range: 4.5V to 75V DC
- Output Voltages: 3.3V, 5V, 12V, 15V (regulated)
- Output Current: 700 mA at 3.3V, 600 mA at 5V, 250 mA at 12V/15V
- Input/Output Isolation: 1.6kVDC
- Efficiency: Up to 83%
- Operating Temperature Range: -40°C to +75°C
- Package: SIP6 encapsulated
- Protection: Short-circuit, overcurrent
- Remote On/Off Control: Yes (single output models)
- Standards: EN55032 compliant
- MTBF: Over 0.95 million hours
- Warranty: 3 years
Buy the XP Power Series DC-DC Converter: ITP0324D12
Purchase the XP Power Series ITP0324D12 today to ensure your industrial applications benefit from a reliable, efficient, and compact 3W DC-DC converter. This module features a wide input voltage range of 4.5V to 75V, regulated outputs from 3.3V to 15V, high efficiency, and advanced safety protections including short-circuit and overload protection. Encased in a tough SIP6 package, it supports harsh environments with operating temperatures from -40°C to +75°C. Perfect for automation, control systems, or embedded applications requiring stable power conversion, order now for fast delivery and enhanced project reliability.
Order your XP Power Series ITP0324D12 today and give your industrial projects the dependable power they deserve with this reliable 3W converter module.
Frequently Asked Questions
Where can I buy XP POWER ITP0324D12?
You can click on the BUY or RFQ button to purchase ITP0324D12 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0324D12?
You can download the ITP0324D12 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0324D12?
XP POWER
