XP POWER ICZ0924S05 DC-DC Converter
The ICZ Series DC-DC Converter offers a compact 9-watt power solution with a small SIP8 package, ideal for space-constrained applications. It provides fully regulated output with no minimum load requirement, remote On/Off control, and a broad -40°C to +85°C operating temperature range. Featuring 2:1 input voltage range, 1.6kVDC input-to-output isolation, and high efficiency up to 87%, this converter is suitable for industrial, automation, and control systems. Its durable epoxy case and copper construction ensure reliable performance in demanding environments.
XP POWER ICZ0924S05 DC-DC Converter Specifications:
- Power Rating: 9 Watts
- Package: SIP8, ultra-compact design
- Input Voltage Range: 18V to 36V, 36V to 75V, -40°C to +85°C operating temperature
- Isolation Voltage: 1.6kVDC input to output
- Output Voltage Options: 3.3V, 5V, 12V, 15V, etc., with fully regulated output
- Efficiency: Up to 87%
- Remote On/Off control: Yes, with max voltage 5V and max current 4mA
- Dimensions: 0.86 x 0.38 x 0.44 inches (21.8 x 9.6 x 11.2 mm)
- Operating Temperature: -40°C to +85°C, with derating above +50°C
- Protection: Overload, short circuit with auto recovery
- Isolation: 1.6kVDC input-to-output, 7000VDC input-to-case
- Insulation Resistance: 50 PF capacitance, functional insulation
- Switching Frequency: 00/500 KHz
- Enclosure: Epoxy potting, copper case, solder coated pins
- MTBF: 300,000 hours (MIL-HDBK-217F)
- Standards: UL/cUL 60950-1, 62368-1, EMI immunity compliant
Buy the XP Power Series ICZ 9W DC-DC Converter: ICZ0924S05
Purchase the XP Power Series ICZ 9W DC-DC Converter online today to ensure reliable, regulated power for industrial, automation, and control applications. Its compact SIP8 package fits easily into space-constrained designs, delivering up to 87% efficiency and a broad -40°C to +85°C operating temperature range. With features such as 1.6kVDC input-output isolation, remote On/Off control, and no minimum load requirement, this converter offers a robust power solution. Enjoy quick delivery and excellent customer support when you buy online now.
Order your XP Power Series ICZ 9W DC-DC Converter today and give your projects the dependable, high-efficiency power they need for demanding environments.
Frequently Asked Questions
Where can I buy XP POWER ICZ0924S05?
You can click on the BUY or RFQ button to purchase ICZ0924S05 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ICZ0924S05?
You can download the ICZ0924S05 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ICZ0924S05?
XP POWER
