XP POWER ISC0324D12 Datasheet & Stock

The ISB03 series is a 3W, regulated single and dual output DC to DC converter with a wide 4:1 input range in a compact SMD package with input to output isolation of 1500VDC and features continues short circuit protection with auto recovery. The series is approved to IEC60950-1 and UL/cUL60950-1 standards.




Regulated Single & Dual Outputs

Wide 4:1 Input Range

Compact SMD Package

1500VDC Isolation

Operating Temperature -40°C to 100°C

Remote on/off

Initial set accuracy of ±2%, line regulation of ±0.5% and load regulation of ±0.5%

Switching frequency of 350KHz

0.94inch x 0.71inch x 0.32inch (24mm x 18.1mm x 8.25mm) dimension and weight is 4.2g

Operating temperature range from -40°C to 100°C





Applications


Power Management,

Industrial
