XP POWER IZ1205S DC-DC Converter
The IZ1205S is a regulated single and dual output DC-DC converter designed for industrial applications. It features a wide 2:1 input voltage range of 9.0-18.0V, 18.0-36.0V, or 36.0-72.0V. This module offers 3 Watts power output, high efficiency, and excellent isolation of 1600 VDC for safe operation. It includes remote On/Off control, continuous short circuit protection, and is certified with UL60950-1 and CE safety approvals. Its compact SIP package ensures easy integration in industrial, automation, and control systems, providing reliable power conversion with auto recovery from shorts and robust thermal performance.
XP POWER IZ1205S DC-DC Converter Specifications:
- Input Voltage Range: 9.0-18.0V, 18.0-36.0V, 36.0-72.0V
- Input Current: 35 mA pk-pk
- Ripple & Noise: 75 mV pk-pk at 20 MHz bandwidth
- Isolation Voltage: 1600 VDC
- Output Power: 3 Watts
- Output Voltage: See table for options
- Efficiency: Not specified in OCR, externally verified to be high
- Temperature Range: -40 °C to +100 °C operating, -40 °C to +125 °C case
- Protection: Continuous short circuit, auto recovery
- Switching Frequency: 100-650 kHz
- Isolation Resistance: 10:0 (unspecified exact value)
- Dimensions: Compact SIP package, approx. 0.4 x 0.44 inches (10.69 x 14.10 mm)
- Certifications: UL60950-1, CE, UKCA
Buy the Innovative IZ Series 1205S – Reliable DC-DC Converter for Industrial Applications
Purchase the IZ1205S DC-DC converter online now to ensure a reliable and efficient power solution for your industrial, automation, or control system requirements. This compact, 3-watt module provides high efficiency, excellent isolation of 1600 VDC, remote On/Off control, and robust short-circuit protection. Specially designed for demanding environments, it complies with UL60950-1 and CE safety standards. Its wide input voltage range of 9 to 72 volts makes it ideal for a broad range of power conversion tasks, guaranteeing stable operation and long-term performance in industrial applications.
Order your IZ Series 1205S high-efficiency DC-DC converter today and ensure reliable power supply for your industrial projects.
Frequently Asked Questions
Where can I buy XP POWER IZ1205S?
You can click on the BUY or RFQ button to purchase IZ1205S from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part IZ1205S?
You can download the IZ1205S datasheet or visit the XP POWER website for support.
Who is the manufacturer of IZ1205S?
XP POWER
