XP POWER STR05S09 Switching Regulator
The STR05S09 from XP Power is a 0.5A regulated single-output switching regulator in a compact SMD package. It features a wide input voltage range of 11V to 32V and provides a fixed 9V output with a maximum current of 500mA. The regulator offers high efficiency, with a minimum of 92% and a maximum of 96%, and includes continuous short circuit protection with auto recovery. It has line regulation of ±0.2% (1.5V to 6.5V) and ±0.1% (9V to 15V), as well as load regulation of ±0.4% (1.5V to 6.5V) and ±0.25% (9V to 15V). The device supports a maximum capacitive load of 220μF, an input current of 5mA at no load, and a remote on/off control with an input current of 24V. Additional features include a trim range from 4.5V to 12.6V, ripple and noise levels of 30mV pk-pk (1.5V to 6.5V) and 40mV pk-pk (9V to 15V), an initial set accuracy of ±2%, switching frequency of 330kHz, dimensions of 15.3mm x 12.35mm x 9.24mm, weight of 1.7g, and an operational temperature range from -40°C to 100°C. Suitable applications include power management and industrial systems.
XP POWER STR05S09 Switching Regulator Specifications:
- Input Voltage Range: 11V to 32V
- Output Voltage: 9V
- Maximum Output Current: 500mA
- Efficiency: 92% to 96%
- Dimensions: 15.3mm x 12.35mm x 9.24mm
- Weight: 1.7g
- Operating Temperature Range: -40°C to 100°C
- Ripple & Noise: 30mV pk-pk (1.5V to 6.5V), 40mV pk-pk (9V to 15V)
- Line Regulation: ±0.2% (1.5V to 6.5V), ±0.1% (9V to 15V)
- Load Regulation: ±0.4% (1.5V to 6.5V), ±0.25% (9V to 15V)
- Capacitive Load: Max 220μF
- Remote On/Off: Yes, input current 24V
- Switching Frequency: 330kHz
- Initial Set Accuracy: ±2%
- Protection: Continuous short circuit with auto recovery
Buy the XP Power STR05S09 – Reliable Switching Regulator for Industrial Applications
Purchase the XP Power switching regulator online today and enhance your power management solutions. With high efficiency up to 96%, reliable short circuit protection, and a compact SMD package, it is ideal for industrial applications requiring stable voltage regulation. Easy to integrate with remote on/off control, support for up to 220μF capacitive load, and operation from -40°C to 100°C, this regulator guarantees performance and durability. Order now to optimize your power supply systems effortlessly.
Buy XP Power STR05S09 now and experience unmatched reliability, high efficiency, and compact design for power management in industrial systems.
Frequently Asked Questions
Where can I buy XP POWER STR05S09?
You can click on the BUY or RFQ button to purchase STR05S09 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part STR05S09?
You can download the STR05S09 datasheet or visit the XP POWER website for support.
Who is the manufacturer of STR05S09?
XP POWER
