DELTA ELECTRONICS / FANS ASB02512VHAA76N Axial Cooling Fan
This axial flow DC fan features a 12 V DC rated voltage and operates between 4.75 and 13.8 V DC. It delivers up to 13000 RPM with maximum airflow of 0.095 m³/min and air pressure of 5.43 mmH₂O. Its noise level is approximately 27 dB-A, with ultralow acoustics tested at 12V. Constructed for reliability, it includes UL class A insulation, robust bearings, and protection features against overload and reverse polarity. Suitable for cooling applications in electronics, servers, and industrial equipment, ensuring efficient airflow and durability.
DELTA ELECTRONICS / FANS ASB02512VHAA76N Axial Cooling Fan Specifications:
- Rated Voltage: 12 VDC
- Operation Voltage Range: 4.75 - 13.8 VDC
- Input Current: 0.05 A (Max. 0.12 A)
- Input Power: 0.60 W (Max. 1.44 W)
- Speed: 13000 RPM
- Max Airflow: 0.095 m³/min
- Air Pressure: 5.43 mmH₂O
- Sound Level: 27 dB-A (Max), 25 dB-A (Test conditions: 12V, Distance 10cm)
- Insulation: UL Class A
- Operating Temperature Range: Not specified (external research suggests -10°C to +70°C)
- Storage Temperature: Up to +75°C
- Operating Humidity: 5% - 90% RH
- Storage Humidity: 5% - 95% RH
- Protection Features: Locked rotor, polarity protection
- Life Expectancy: 30,000 hours at 40°C (per external datasheet)
- Environmental Compliance: RoHS
- Mechanical Dimensions: Approximate frame size 55mm, weight 60g
- Material: Metal frame, plastic impeller, ball bearing system
Buy the Delta Series Axial Cooling Fan: ASB02512VHA-A76N
Enhance your cooling system with our high-performance 12V axial fan. Designed for durability, low noise, and efficient airflow, this fan fits various electronic, industrial, and server applications. With UL Class A insulation and protection features, it guarantees safe and reliable operation. Easy to install and compatible with multiple systems, purchase this Delta axial fan online today and experience seamless cooling performance for your equipment. Ensure your projects stay cool and efficient with this dependable solution.
Order your Delta SeriesASB02512VHA-A76N axial cooling fan today and ensure optimal airflow and reliable cooling for your electronic and industrial projects.
