DELTA ELECTRONICS / FANS AFB0424SHB Cooling Fan
The DC axial flow fan features a 24 VDC rated voltage with operating voltage between 14.0 and 27.6 VDC. It is equipped with two ball bearings, made of UL: 94V-0 plastic, with dimensions specified in the detailed drawing. Designed for continuous operation, it has an estimated lifespan of 70,000 hours at 40°C with 15-65% humidity. The fan produces a maximum noise level of 44.5 dB-A, operates reliably across temperature ranges from -10°C to +70°C, and includes features such as polarity and locked rotor protections. Ideal for cooling electronic equipment with dimensions specified for optimal airflow and efficiency.
DELTA ELECTRONICS / FANS AFB0424SHB Cooling Fan Specifications:
- Rated Voltage: 24 VDC
- Operation Voltage: 14.0 – 27.6 VDC
- Input Current: 0.12 (MAX. 0.18) A
- Input Power: 2.88 (MAX. 4.82) W
- Speed: 11000 R.P.M. (REF.)
- Max Air Flow: 0.420 (MIN. 0.278) M3/MIN or 14.83 (MIN. 18.95) CFM
- Max Air Pressure: 15.26 (MIN. 12.40) mmH2O or 0.601 (MIN. 0.488) inchH2O at zero airflow
- Acoustical Noise: 41.5 (MAX. 44.5) dB-A
- Insulation Type: UL: CLASS A
- Insulation Strength: 10 Meg Ohm MIN. at 500 VDC
- Dielectric Strength: 5 mA MAX. at 500 VAC 60 Hz for 1 min
- Dimensions: As per drawing, approximately 40.0 mm x 40.0 mm
- Frame and Impeller: UL 94V-0 plastic
- Bearing System: Two ball bearings
- Weight: 25 grams
- Environmental Conditions: Operating temperature -10°C to +70°C, Storage -40°C to +75°C, humidity 5-90% RH
- Protection Features: Locked rotor, polarity protection
- Lifespan: 70,000 hours continuous use at 40°C
- Material: UL 94V-0 plastic for frame and impeller
- Connection: UL 1007 -F- AWG #24 lead wires, black negative, red positive
Buy the Delta Series AFB0424SHB Cooling Fan: 24 VDC Axial Fan
Order the Delta Series AFB0424SHB cooling fan online today and enjoy reliable performance for your electronic cooling needs. With a rated voltage of 24 VDC, this axial fan features two durable ball bearings, UL 94V-0 plastic frame and impeller, and provides optimal airflow with a maximum noise level of 44.5 dB-A. Designed for continuous operation with a lifespan of 70,000 hours, it offers excellent vibration, vibration, and temperature resilience. Perfect for industrial, hardware, and electronic cooling applications, this fan ensures efficient heat dissipation and quiet operation, making it an ideal choice for demanding environments.
Get Delta Series AFB0424SHB cooling fan today—built for precision airflow, long-lasting durability, and optimal electronic cooling.
Frequently Asked Questions
Where can I buy DELTA ELECTRONICS / FANS AFB0424SHB?
You can click on the BUY or RFQ button to purchase AFB0424SHB from an authorized DELTA ELECTRONICS / FANS distributor.
How do I troubleshoot issues or seek technical support for part AFB0424SHB?
You can download the AFB0424SHB datasheet or visit the DELTA ELECTRONICS / FANS website for support.
Who is the manufacturer of AFB0424SHB?
DELTA ELECTRONICS / FANS
