DELTA ELECTRONICS / FANS ASB0305LAD Brushless DC Fan
The DC fan is a brushless cooling device designed for reliable performance in electronic equipment. Operating at 5 VDC with a rated current of 0.10A, it delivers an airflow of 0.091 m³/min and a noise level of 21 dB-A. Constructed with UL: Class A insulation and a sleeve bearing system, it features a plastic frame and impeller. The fan has a lifespan of approximately 20,000 hours at 40°C, with a maximum static pressure of 3.33 mmH₂O. Suitable for environments requiring efficient thermal management, it complies with RoHS standards and offers reversibility and protection features.
DELTA ELECTRONICS / FANS ASB0305LAD Brushless DC Fan Specifications:
- Rated Voltage: 5 VDC
- Operation Voltage Range: 4.5 - 5.5 VDC
- Minimum Start Voltage: 4.0 VDC
- Input Current: 0.10 A (Max. 0.17 A)
- Input Power: 0.50 W (Max. 0.85 W)
- Speed: 8000+15% RPM
- Max. Air Flow: 0.091 m3/min
- Max. Air Pressure: 3.33 mmH2O
- Acoustical Noise: 21.0 dB-A (Max. 25.5 dB-A)
- Insulation Type: UL: Class A
- Insulation Strength: >= 10 MΩ at 500 VDC
- Dielectric Strength: 5 mA Max. at 500 VAC
- External Cover: Open Type
- Life Expectancy: 20,000 hours
- Rotation: Counterclockwise from front view
- Lead Wires: UL 1061 AWG #28, Black (Negative), Red (Positive)
- Operating Temperature: -10°C to +70°C
- Storage Temperature: -40°C to +75°C
- Operating Humidity: 5% to 90% RH
- Storage Humidity: 5% to 95% RH
- Material: Plastic UL: 94V-0
- Bearing System: Sleeve Bearing
- Weight: 7.4 grams
- Environmental Compliance: RoHS
- Production Location: China or Thailand
Buy the Delta Series ASBO305LA-D Fan: ASBO305LA-D
Enhance your electronic cooling systems with the high-performance Delta Brushless DC Fan. Operating at 5V with quiet operation, prolonged lifespan of 20,000 hours, and reliable insulation, this fan is ideal for thermal management in sensitive electronic devices. Featuring a maximum airflow of 0.091 m³/min and a compact plastic frame, it guarantees efficient cooling with minimal noise. Order online today to ensure your projects benefit from this dependable, high-quality cooling solution, perfect for various industrial and electronic applications.
Order your Delta Series ASBO305LA-D fan today and enhance your electronic cooling solutions with this reliable, quiet brushless fan.
