DELTA ELECTRONICS / FANS AFB0412SHBF00 DC Fan
This high-performance DC brushless axial flow fan features a 12VDC rated voltage and operates between 7.0 and 13.8VDC. It delivers a maximum airflow of 0.878 CFM and a maximum air pressure of 0.601 inchesH2O, with a noise level not exceeding 44.5 dB-A. Equipped with two ball bearings and made of UL 94V-0 plastic, it boasts a lifespan of approximately 70,000 hours at 40°C. Ideal for cooling applications in electronic equipment and industrial systems, it ensures reliable, quiet operation suitable for continuous use.
DELTA ELECTRONICS / FANS AFB0412SHBF00 DC Fan Specifications:
- Rated Voltage: 12 VDC
- Operation Voltage: 7.0 - 13.8 VDC
- Input Current: 0.25 A (max. 0.95 A)
- Input Power: 3.00 W (max. 4.20 W)
- Speed: 11,000 R.P.M. (ref.)
- Max Air Flow: 0.878 CFM (MIN. 13.35) at zero static pressure
- Max Air Pressure: 0.601 inchH2O (MIN. 0.488) at zero airflow
- Acoustical Noise: 41.5 dB-A (MAX. 44.5 dB-A)
- Insulation Type: UL Class A
- Insulation Strength: 10 MΩ MIN. at 500 VDC
- Dielectric Strength: 5 mA MAX. at 500 VAC 60 Hz, 1 min
- External Cover: Open type
- Lifespan: 70,000 hours continuous operation at 40°C with 15-65% RH
- Mechanical Dimensions: see drawing
- Frame: Plastic UL 94V-0
- Impeller: Plastic UL 94V-0
- Bearings: Two ball bearings
- Weight: 25 grams
- Operating Temperature: -10°C to +70°C
- Storage Temperature: -40°C to +75°C
- Operating Humidity: 5% to 90% RH
- Storage Humidity: 5% to 95% RH
- Protection: Locked rotor and polarity protection
- Material: Plastic UL 94V-0
- Produced in: China, Thailand, or Taiwan
Buy the Buy Delta DC Fan Part Number AFB0412SHB-F00 Online
Order the Delta AFB0412SHB-F00 DC fan today to ensure reliable cooling performance for your electronic and industrial systems. Featuring a lifespan of 70,000 hours, UL Class A insulation, and quiet operation at up to 44.5 dB-A, this axial fan is ideal for continuous use in various environments. Easy to install with robust plastic construction, it guarantees excellent airflow and static pressure capabilities. Purchase online now for fast delivery, competitive pricing, and confidence in quality and durability.
Get Delta AFB0412SHB-F00 today—designed for dependable cooling with quiet operation and long-lasting durability.
Frequently Asked Questions
Where can I buy DELTA ELECTRONICS / FANS AFB0412SHBF00?
You can click on the BUY or RFQ button to purchase AFB0412SHBF00 from an authorized DELTA ELECTRONICS / FANS distributor.
How do I troubleshoot issues or seek technical support for part AFB0412SHBF00?
You can download the AFB0412SHBF00 datasheet or visit the DELTA ELECTRONICS / FANS website for support.
Who is the manufacturer of AFB0412SHBF00?
DELTA ELECTRONICS / FANS
