DELTA ELECTRONICS / FANS EFB0512HA Axial Flow Fan
This axial flow DC fan operates at 12V and features a two-phase, four-pole motor design for reliable performance in electronic cooling applications. It has a high airflow capacity of 19.323 m³/min and a maximum speed of 5500 RPM. The fan's plastic frame and impeller meet UL: 94V-0 flame retardant standards, ensuring safety and durability. Designed for continuous operation up to 70,000 hours at 40°C, it offers features like locked rotor and polarity protection, with a lightweight of 25 grams. Suitable for industrial and electronic cooling environments, it performs effectively across temperatures from -10°C to +70°C and humidity 5-90% RH.
DELTA ELECTRONICS / FANS EFB0512HA Axial Flow Fan Specifications:
- Rated Voltage: 12 V
- Operation Voltage Range: 7-138 V
- Input Current: 0.10 A (max 0.15 A)
- Input Power: 1.20 W (max 1.80 W)
- Speed: 5500 RPM (ref.)
- Max Airflow: 19.323 m³/min (min 0.291 m³/min)
- Max Air Pressure: 4.24 mmH₂O (min 3.43 mmH₂O)
- Max Static Pressure: 0.167 inchH₂O (min 0.135 inchH₂O)
- Sound Level: 30.0 dB-A (max 35.0 dB-A)
- Insulation Type: UL Class A
- Dielectric Strength: 5 mA max at 500 VAC
- Life Expectancy: 70,000 hours continuous operation
- Mechanical Dimensions: Refer to detailed drawing
- Frame Material: UL 94V-0 plastic
- Impeller Material: Plastic UL: 94V-0
- Bearings: Two ball bearings
- Weight: 25 grams
- Operating Temperature: -10°C to +70°C
- Storage Temperature: -40°C to +75°C
- Operating Humidity: 5 to 90% RH
- Storage Humidity: 5 to 95% RH
- Protection Features: Locked rotor and polarity protection
- Environmental Compliance: No PBBs, PBBEs, CFCs, HCFCs
- Production Locations: China, Thailand, Taiwan
Buy the Delta Series EFB0512HA Axial Flow Fan: EFB0512HA
Purchase the Delta axial flow fan EFB0512HA online today and enhance your electronic cooling solutions with this reliable, high-performance fan. Engineered with UL-rated plastic, two ball bearings, and designed for continuous operation up to 70,000 hours, it ensures durability and consistent airflow. Ideal for applications requiring 12V operation, it features low noise levels, built-in protection features, and operates effectively across a wide temperature and humidity range. Buy now and strengthen your cooling system with this dependable industrial component.
Order your Delta Series EFB0512HA axial flow fan today and ensure reliable cooling performance for your electronic projects and industrial equipment.
