DELTA ELECTRONICS / FANS ASB0305MADR00 Axial Cooling Fan
The DC fan is a brushless axial flow fan designed for reliable operation in industrial environments. It features a rated voltage of 5 VDC, with an operational range of 4.5 to 5.5 VDC, and a minimum start voltage of 4.0 VDC. The fan offers an airflow of 0.105 M3/min at zero static pressure, a maximum rotational speed of 9000 RPM, and an acoustical noise level not exceeding 27.5 dB-A at 1 meter. Its durable plastic frame and sleeve bearing ensure a lifespan of approximately 20,000 hours under continuous operation at 25°C, making it suitable for cooling and ventilation applications.
DELTA ELECTRONICS / FANS ASB0305MADR00 Axial Cooling Fan Specifications:
- Rated Voltage: 5 VDC
- Operation Voltage: 4.5 - 5.5 VDC
- Minimum Start Voltage: 4.0 VDC
- Input Current: 0.11 (MAX. 0.19) A
- Input Power: 0.55 (MAX. 0.95) W
- Speed: 9000+15% R.P.M.
- Max. Air Flow: 0.105 (MIN. 0.086) M3/ Min.
- Max. Air Pressure: 4.25 (MIN. 2.86) mmH2O
- Acoustical Noise: 23.0 (MAX. 27.5) dB-A
- Insulation Type: UL Class A
- Lifetime: approximately 20,000 hours
- Operating Temperature: -10°C to +70°C
- Storage Temperature: -40°C to +75°C
- Environmental Humidity: 5% to 90% RH
- Frame Material: Plastic UL: 94V-0
- Bearing System: Sleeve bearing
- Lead Wires: UL 1061 AWG #28 (Black negative, Red positive, Blue lock signal)
Buy the Delta ASBO305MA – Reliable Cooling Fan for Industrial Applications
Discover the high-performance Delta axial cooling fan with 9000 RPM, low noise, and durable construction designed for industrial environments. With a compact plastic frame, sleeve bearing system, and UL safety classification, this fan is ideal for cooling electronic equipment and ventilation systems. It operates reliably at 5VDC, with a lifespan of up to 20,000 hours under continuous operation at 25°C. Enhanced environmental resistance and safety features ensure top performance and safety in demanding applications. Purchase online today for fast, dependable delivery.
Order your Delta Series ASBO305MA-DRO00 axial fan today and ensure efficient, quiet cooling for your industrial projects with reliable performance.
Frequently Asked Questions
Where can I buy DELTA ELECTRONICS / FANS ASB0305MADR00?
You can click on the BUY or RFQ button to purchase ASB0305MADR00 from an authorized DELTA ELECTRONICS / FANS distributor.
How do I troubleshoot issues or seek technical support for part ASB0305MADR00?
You can download the ASB0305MADR00 datasheet or visit the DELTA ELECTRONICS / FANS website for support.
Who is the manufacturer of ASB0305MADR00?
DELTA ELECTRONICS / FANS
