DELTA ELECTRONICS / FANS ASB0305MAD Cooling Fan
The DC fan is a compact, brushless axial flow fan designed for efficient airflow and reliable operation in electronic cooling applications. It features a plastic UL 94V-0 frame and impeller, with a rated voltage of 5 VDC and an operational voltage range of 4.5 to 5.5 VDC. The fan operates at approximately 9000 RPM, providing a maximum airflow of 0.105 m3/min (3.72 CFM) and a maximum air pressure of 4.25 mmH2O (0.167 inchH2O). It has an insulation type UL Class A, an expected life of 20,000 hours, and is equipped with sleeve bearings, making it suitable for continuous operation in various environments.
DELTA ELECTRONICS / FANS ASB0305MAD Cooling Fan Specifications:
- Rated Voltage: 5 VDC
- Operation Voltage: 4.5 - 5.5 VDC
- Minimum Start Voltage: 4.0 VDC
- Input Current: 0.11 A (max 0.19 A)
- Input Power: 0.55 W (max 0.95 W)
- Speed: approximately 9000 RPM
- Max Air Flow: 0.105 m3/min (3.72 CFM)
- Air Pressure (Max): 4.25 mmH2O (0.167 inchH2O)
- Sound Level (Average at 1.0m): 23.0 dB-A (max 27.5 dB-A)
- Insulation Type: UL Class A
- Insulation Resistance: 10 MΩ min at 500 VDC
- Dielectric Strength: 5 mA max at 500 VAC, 50/60 Hz
- Life Expectancy: 20,000 hours
- Operating Temperature: -10°C to +70°C
- Storage Temperature: -40°C to +75°C
- Operating Humidity: 5% to 90% RH
- Storage Humidity: 5% to 95% RH
- Frame Material: Plastic UL 94V-0
- Impeller Material: Plastic UL 94V-0
- Bearing System: 2+ Sleeve Bearings
- Lead Wires: UL 1061 AWG #28, Black (Negative), Red (Positive)
- Rotation Direction: Counterclockwise from front view
- Protection: Locked rotor protection, Polarity protection
- Application: Electronic cooling, ventilation for electronic equipment
Buy the Buy Delta Cooling Fan Part Number ASBO305MA-D Online
Purchase the Delta cooling fan online today to ensure optimal airflow and reliable operation in electronic devices. This high-quality compact axial fan offers a lifespan of 20,000 hours, operating efficiently at 5 VDC with a maximum airflow of 0.105 m3/min. Its UL Class A insulation and sleeve bearings make it suitable for continuous use in various environments, providing excellent cooling performance. Easy to install and compatible with a wide range of electronic applications, this fan guarantees durability and consistent cooling, making it the ideal choice for your electronic cooling needs.
Buy Delta ASBO305MA-D now and experience reliable cooling performance with a lifespan of 20,000 hours and high airflow efficiency.
