DELTA ELECTRONICS / FANS AFB0412HHB industrial cooling fan
This is a high-reliability DC brushless axial flow fan designed for industrial and electronic cooling applications. Operating at 12V DC with a speed of approximately 300 RPM, it features a durable plastic frame and impeller meeting UL: 94V-0 standards. The fan includes two ball bearings, with an insulation class of UL: Class A, ensuring safe operation under various environmental conditions. It has a long lifespan of 70,000 hours at 40°C, with protection features like locked rotor and polarity safeguards to prevent damage. Ideal for systems requiring efficient airflow and low noise.
DELTA ELECTRONICS / FANS AFB0412HHB industrial cooling fan Specifications:
- Rated Voltage: 12V DC
- Operation Voltage Range: 7.0 - 13.8 VDC
- Input Current: 0.13 A (Max. 0.20 A)
- Input Power: 1.56 W (Max. 2.40 W)
- Speed: ~300 RPM (Ref.)
- Air Flow: 0.325 m3/min (Min. 0.292), 11.48 CFM (Min. 10.31)
- Max Air Pressure: 9.13 mmH20 (Min. 7.40), 0.959 inchH2O (Min. 0.291)
- Noise Level: Max. 35.0 dB-A
- Insulation: UL Class A
- Dielectric Strength: 5 mA Max. at 500 VAC 60Hz
- Life Expectancy: 70,000 hours at 40°C
- Frame Material: UL 94V-0 Plastic
- Impeller Material: UL 94V-0 Plastic
- Bearing System: Two ball bearings
- Weight: 25 grams
- Operating Temperature: -10°C to +70°C
- Storage Temperature: -40°C to +75°C
- Operating Humidity: 5-90% RH
- Storage Humidity: 5-70%, 95% RH
- IP Protection: Not specified, open type
- Vibration and Shock Resistance: Includes vibration level of 3.2 gRMS, 20 G shocks
- Mounting: Suitable for external mounting with proper safety measures
- Compliance: RoHS compliant, no PBBs, PBBOs, CFCs, PBBEs, PBDPEs, HCFCs
Buy the Delta AFB0412HHB – Reliable Cooling Fan for Industrial Applications
Purchase the Delta AFB0412HHB online today to upgrade your electronic and industrial cooling systems. This high-quality, reliable fan offers excellent airflow, long service life of 70,000 hours, advanced safety features, and is built to operate efficiently under various environmental conditions. Featuring UL Class A insulation and robust construction, it ensures safe, quiet performance for HVAC, servers, and electronic equipment. Secure your supply and enjoy fast delivery, dependable operation, and warranty support by ordering now through our online store.
Order your Delta Series AFB0412HHB today and ensure optimal thermal management with this durable, efficient cooling fan for demanding industrial environments.
