DELTA ELECTRONICS / FANS ASB0305HADR00 Cooling Fan
This is a 5V DC brushless fan designed for efficient airflow and durability in various industrial and electronic cooling applications. It features a compact size with a plastic UL 94V-0 frame and impeller, sleeve bearing system, and an open external cover. The fan operates at 10500 RPM with a maximum airflow of 0.122 m³/min, producing an acoustical noise level up to 32 dB-A. It offers a life expectancy of 20,000 hours, with insulation and dielectric strength conforming to UL standards. Suitable for environments from -10°C to +70°C, it includes leakage and rotation detection features, making it ideal for cooling and ventilation systems.
DELTA ELECTRONICS / FANS ASB0305HADR00 Cooling Fan Specifications:
- Rated Voltage: 5 VDC
- Operation Voltage: 4.5 - 5.5 VDC
- Min. Start Voltage: 4.0 VDC
- Input Current: 0.14 A (Max. 0.24 A)
- Input Power: 0.70 W (Max. 1.20 W)
- Speed: 10500 RPM ±15%
- Max Air Flow: 0.122 m³/min (Min. 0.103 m³/min)
- Air Flow: 4.30 CFM (Min. 3.65 CFM)
- Max Air Pressure: 5.44 mmH2O (Min. 3.93 mmH2O)
- Max Air Pressure in InchesH2O: 0.214 (Min. 0.154)
- Acoustical Noise: 27.0 dB-A (Max. 32.0 dB-A)
- Insulation Type: UL: Class A
- Insulation Resistance: ≥10 Meg Ohm at 500 VDC
- Dielectric Strength: ≥5 mA at 500 VAC 50/60 Hz for one minute
- External Cover: Open type
- Life Expectancy: 20,000 hours at 40°C, 65% RH
- Rotation: Counterclockwise from front view
- Lead Wires: UL 1061 AWG #28, Black (negative), Red (positive), Blue (lock signal)
- Operable Temperature: -10°C to +70°C
- Storage Temperature: -40°C to +75°C
- Operating Humidity: 5% to 90% RH
- Storage Humidity: 5% to 95% RH
- Bearing System: Sleeve bearing
- Material: Plastic UL 94V-0
- Dimensions: Refer to drawing (approximate size 24mm x 24mm x 10mm)
Buy the Delta ASBO305HA – Reliable Cooling Fan for Industrial Applications
Order the Delta ASBO305HA-DROO cooling fan today to ensure reliable airflow and cooling for your electronic and industrial equipment. Designed for 5V DC operation, it features a compact and durable plastic UL 94V-0 frame, a sleeve bearing system for smooth operation, and an open external cover for easy installation. With a lifespan of 20,000 hours, it operates efficiently at up to 10500 RPM, providing a maximum airflow of 0.122 m³/min. Perfect for continuous cooling in demanding environments, this fan guarantees performance and longevity.
Get Delta ASBO305HA-DROO today—built for precision and long-lasting durability in electronic cooling systems.
