OMEGA LC103B20K Stainless Steel Load Cell
Omega's LC103B20K stainless steel S-beam load cell offers high accuracy and durable performance for tension and compression applications. Designed to meet OIML R60 C3 standards, it provides excellent linearity and temperature stability. Its rugged stainless steel construction ensures corrosion resistance and ingress protection to IP67, suitable for harsh environments. Ideal for crane scales, hopper weighing, tank measurement, and truck scales, this load cell is easy to install with a safe overload capacity of 150% and features a 4-conductor shielded cable for reliable signal transmission.
OMEGA LC103B20K Stainless Steel Load Cell Specifications:
- Capacity: 20,000 Ib (9072 kg)
- Material: Stainless steel
- Accuracy: Class C3
- Approvals: OIML R60
- Output Sensitivity: 3.04 ± 0.008 mV/V
- Maximum Load Cell Intervals: 3000
- Combined Error: ±0.020% FS
- Safe Overload: 150%
- Ultimate Overload: 300%
- Zero Balance: ±1.0% FS
- Excitation Voltage: 5-12 V DC, max 18 V DC
- Input Resistance: 430 ± 60 Ω
- Output Resistance: 351 ± 2 Ω
- Insulation Resistance: ≥5000 MΩ at 50 V DC
- Operating Temperature: -35°C to 65°C
- Storage Temperature: -40°C to 70°C
- Ingress Protection: IP67
- Element Material: Stainless steel
- Recommended Fixation Torque: 1/4" UNF: 18 lb·ft, 1/2" UNF: 55 lb·ft, 3/4" UNF: 330 lb·ft, 1 1/8" UNF: 1070 lb·ft
Buy the Buy Omega Load Cell Part Number LC103B20K Online
Order the Omega LC103B20K stainless steel load cell online today for reliable tension and compression measurements. Its high accuracy, robust construction, and IP67 water and dust resistance make it suitable for demanding industrial applications like crane scales, tank weighing, and hopper measurement. Easy to install with a safe overload capacity of 150%, it ensures durability and dependable performance over time. Perfect for those who require precision and robustness in their weighing systems—shop now for fast delivery and expert support.
Get Omega LC103B20K today—designed for high precision and long-lasting durability in harsh environments.
Frequently Asked Questions
Where can I buy OMEGA LC103B20K?
You can click on the BUY or RFQ button to purchase LC103B20K from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part LC103B20K?
You can download the LC103B20K datasheet or visit the OMEGA website for support.
Who is the manufacturer of LC103B20K?
OMEGA
