TRACO POWER TBLC90112 Industrial Power Supply
The TBLC Series power supplies provide efficient, compact, DIN-rail mountable solutions for industrial and residential applications. These low-profile modules feature a universal input range of 85 to 264 VAC, adjustable output voltage, and high efficiency exceeding ECO standards. Built with safety and reliability in mind, they include short circuit, overload protection, and a DC-OK indicator LED. With an operating temperature range of -25°C to +70°C and conformance to UL 1310, UL 508, and IEC standards, these power supplies are ideal for distributed power applications in household and industrial environments.
TRACO POWER TBLC90112 Industrial Power Supply Specifications:
- Input Voltage Range: 85-264 VAC, 50/60 Hz
- Output Power: 6W to 90W
- Output Voltage: 5.0-5.5 VDC, 12-16 VDC, 24-28 VDC (adjustable)
- Output Current: Up to 40A
- Efficiency: >74% to >89%
- Operating Temperature: -25°C to +70°C
- Dimensions: Width varies from 18mm to 90mm, depth 55mm
- Protection: Short circuit, overload, overvoltage
- Certifications: UL 1310, UL 508, IEC/EN 60950-1, EN 60204
- Environmental: RoHS, conform to ECO standards, pollution degree 2
- Leakage Current: 0.25 mA max.
- MTBF: >1.9 million hours
- Mounting: DIN-rail (EN 50022) or wall/ chassis with supplied bracket
- Safety Class: II, IP20
Buy the Buy Traco Power TBLC Series Power Supply Part Number TBLC90112 Online
Purchase the Traco Power TBLC90112 power supply online today for a reliable, high-efficiency solution suited for industrial and residential needs. Designed with compact dimensions and safety features, it offers adjustable output voltage, short circuit and overload protection, and a robust safety certification. Ideal for distributed power and panel mounting, this versatile module ensures consistent performance in temperatures from -25°C to +70°C. Enjoy easy online ordering and fast delivery for your critical power requirements, ensuring dependable operation in diverse environments.
Get Traco Power TBLC90112 today—compact, efficient, and built for industrial and residential applications.
