TRACO POWER TEN62413WIN DC/DC Converter
The POWER TEN 6WIN series offers high-efficiency 6 Watt DC/DC converters designed for cost-critical applications with a compact DIP-24 package. These converters feature wide input voltage ranges of 9-36 VDC or 18-75 VDC, high isolation voltages of 1500 VDC or 3000 VDC, and operate reliably from -40°C to +85°C. Equipped with overload protection, low ripple, and noise, they meet industrial standards such as IEC 60950 and UL 60950, and come with certifications including CB, UL, and CSA. Ideal for industrial automation, medical, and control systems requiring stable power supplies.
TRACO POWER TEN62413WIN DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC or 18-75 VDC
- Output Power: 6 Watt
- Isolation Voltage: 1500 VDC or 3000 VDC
- Operating Temperature: -40°C to +85°C
- Efficiency: up to 84%
- Ripple and Noise: 80 mVp-p max
- Output Voltage Tolerance: ±22%
- Line Regulation: 0.5%
- Load Regulation: 1.2%
- Surge Voltage: 50 V or 100 V max
- Humidity: 95% rel H max
- MTBF: >800,000 hours
- Switching Frequency: 330 kHz
- Soldering Temperature: max 260°C
- Certifications: IEC 60950, UL 60950, CB, CSA, RoHS, Reach
- Weight: 180 g
- Casing Material: UL 94V-O-rated plastic
- Potting Material: epoxy
Buy the Buy TracoPower DC/DC Converter Part Number TEN62413WIN Online
Get the reliable TracoPower TEN62413WIN DC/DC converter online today. Designed for industrial and automation systems, it offers high efficiency, wide input voltage, high isolation, and a compact DIP-24 package. This 6 Watt power module features overload protection, low ripple, and noise, providing stable and safe power conversion over a broad temperature range from -40°C to +85°C. Perfect for demanding applications needing high performance and compliance with international safety standards, available now for quick online ordering.
Order your TracoSeries TEN62413WIN high-efficiency power converter today and ensure reliable power delivery for your industrial and control projects.
