XP POWER FGSMA04BFR Medical Power Inlet
The device combines a double-pole front-accessible switch, dual fuse holder, and low earth-leakage filtered IEC 320-C14 inlet within a compact metal housing. Designed for medical applications, it provides excellent attenuation of conducted electromagnetic interference (EMI) from the mains supply and reduces emissions from equipment onto the mains. Suitable for Class I appliances, all models feature a shielded metal body, bleed resistor for safe capacitor discharge, and are certified under EN60939-2 and ANSI/UL1283. Operating over -40°C to 110°C, with full power up to 50°C, rated current options include 1A, 2A, 4A, 6A, and 10A, with 6.3 x 0.8mm Faston terminals, screw mount, and double-pole switch, ideal for precise, reliable electrical connections in medical settings.
XP POWER FGSMA04BFR Medical Power Inlet Specifications:
- Rated Voltage: 250 VAG
- Rated Current: 4A (model FGSMA04BFR)
- Input Frequency: 50Hz to 400Hz
- Earth Leakage Current: 2-5 µA
- Operating Temperature Range: -40°C to 110°C
- Full Power Temperature: Up to 50°C
- Protection Class: Suitable for Class I appliances
- Safety Approvals: EN60939-2, ANSI/UL1283
- Terminal Size: 6.3 x 0.8mm Faston
- Leakage Current: 2 µA
- Dielectric Strength: 1500 VAG
- Flammability Rating: UL V-2
- Mounting: Screw Mount
- Construction: Shielded Metal Body
- Includes: Bleed resistor for capacitor discharge
- Rated Voltage: 250 V
- Rated Current Options: 1A, 2A, 4A, 6A, 10A
- Dimensions: Approximate mounting cutout 2.39 x 0.8 inches (60.8 x 20.3 mm)
Buy the XP Power FGSMA04BFR – Reliable Medical Power Inlet for Industrial Applications
Order the XP Power FGSMA04BFR online today to enhance your medical device or industrial equipment with a durable, shielded, and EMI-filtered power inlet. This compact device features a double-pole switch, dual fuse holder, and a robust metal shield to provide reliable power connection and electromagnetic interference attenuation. Perfect for Class I appliances, it operates over a wide temperature range, ensuring safety and performance in critical environments. Faston terminals facilitate secure wiring, making installation straightforward. Trust XP Power’s quality to keep your equipment running smoothly and safely.
Buy XP Power FGSMA04BFR now and ensure reliable power connections with EMI filtering for your medical and industrial equipment.
