DELTA ELECTRONICS / FANS ASB0305LADF00 Brushless Cooling Fan
This high-performance DC brushless fan features a rated voltage of 5 VDC, operating efficiently at 4.5 to 5.5 VDC with a maximum current of 0.17 A. It provides an airflow of 0.077-0.091 m³/min, operates at approximately 8000 RPM, and produces noise levels up to 25.5 dB-A. Constructed with UL: Class A insulation, it boasts a life expectancy of 20,000 hours at 40°C with 65% RH, and includes protective features such as locked rotor and polarity protection. Suitable for various electronic cooling applications, its external open design and durable plastic housing ensure reliability and efficient thermal management.
DELTA ELECTRONICS / FANS ASB0305LADF00 Brushless Cooling Fan Specifications:
- Rated Voltage: 5 VDC
- Operation Voltage: 4.5 - 5.5 VDC
- Min. Start Voltage: 4.0 VDC
- Input Current: 0.10 (MAX. 0.17) A
- Input Power: 0.50 (MAX. 0.85) W
- Speed: 8000±15% R.P.M.
- Max Air Flow: 0.091 (MIN. 0.077) m³/min
- Max Air Pressure: 3.33 (MIN. 2.40) mmH₂O
- Acoustical Noise: MAX. 25.5 dB-A
- Insulation: UL Class A
- Life Expectancy: 20,000 hours
- Rotation: Counterclockwise from front view
- Insulation Resistance: 10 Mega Ohms MIN. at 500 VDC
- Dielectric Strength: 5 mA MAX. at 500 VAC 50/60 Hz for 1 minute
- External Cover: Open Type
- Operating Temperature: -10°C to +70°C
- Storage Temperature: -40°C to +75°C
- Operating Humidity: 5% to 90% RH
- Storage Humidity: 5% to 95% RH
- Lead Wires: UL 1061 AWG #28, Black Negative, Red Positive, Blue Frequency
Buy the Delta Series ASBO305LA Brushless Fan: ASBO305LA-DF00
Discover the durable and efficient Delta brushless cooling fan designed for electronic cooling and ventilation. Operating at 5V DC with an airflow of up to 0.091 m³/min, it ensures optimal thermal management. With a lifespan of 20,000 hours and low noise levels, this fan provides reliable performance for advanced electronic systems. Ideal for use in various industrial and electronic applications, it features UL Class A insulation, durable plastic housing, and protective measures like locked rotor and polarity protection. Purchase online today for dependable cooling solutions.
Buy Delta Series ASBO305LA-D F00 now and experience unmatched reliability and performance in electronic cooling solutions.
Frequently Asked Questions
Where can I buy DELTA ELECTRONICS / FANS ASB0305LADF00?
You can click on the BUY or RFQ button to purchase ASB0305LADF00 from an authorized DELTA ELECTRONICS / FANS distributor.
How do I troubleshoot issues or seek technical support for part ASB0305LADF00?
You can download the ASB0305LADF00 datasheet or visit the DELTA ELECTRONICS / FANS website for support.
Who is the manufacturer of ASB0305LADF00?
DELTA ELECTRONICS / FANS
