OMEGA CN7853 Process Controller
The CN7200 series DIN rail temperature and process controllers provide versatile and precise control for industrial heating and cooling applications. Compatible with thermocouples, RTDs, DC voltage, or current inputs, these controllers feature dual 4-digit LED displays for process and setpoint monitoring. They support multiple control methods including ON/OFF, PID, and autotune, with 8 ramp/soak programs and alarms for enhanced process management. Featuring RS485 communications, a robust IP66 front rating, and various output options, these units ensure reliable industrial automation performance.
OMEGA CN7853 Process Controller Specifications:
- Inputs: Thermocouple types K, J, T, E, N, R, S, L, U, Pt 100 RTD, 0-50 mV, 0-5V, 0-10V, 4-20 mA
- Display: Two 4-digit, 7-segment LED PV in red, 19 mm; SV in green, 12.7 mm
- Control Outputs: Relay SPDT 5A @ 250 Vac, DC pulse 14V/10-20%, 4-20 mA, linear voltage 0-5V/0-10V
- Accuracy: ±0.25% span, ±1 digit, Power: 100-240 Vac, 50/60 Hz, Consumption: 5 VA
- Temperature Range: 0-50°C, Mechanical Dimensions: 96 x 96 x 15.8 mm bezel, IP66 front rating, Weight: 425 g
- Memory Backup: Nonvolatile, Communication: RS485 MODBUS RTU, Panel Cutout: 92 mm, Panel Depth: 79.2 mm
- Accessories include dual output modules for DC pulse, relay, 4-20 mA, and voltage outputs
Buy the Omega CN7200 U+2013 Reliable Process Control for Industrial Applications
Order the Omega CN7200 process controller online today to secure reliable temperature and process management for your industrial automation systems. Featuring versatile input options, dual 4-digit LED displays, multiple control modes including PID and autotune, and RS485 communication, this controller is ideal for precise process control. Its robust IP66 rated front ensures durability in harsh environments. Easy to install, with comprehensive accessories and configurable alarm functions, it's your trusted solution for efficient industry automation—order now to improve your system performance.
Buy Omega CN7200 now and experience unmatched reliability and precision for your industrial heating and cooling control needs.
Frequently Asked Questions
Where can I buy OMEGA CN7853?
You can click on the BUY or RFQ button to purchase CN7853 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part CN7853?
You can download the CN7853 datasheet or visit the OMEGA website for support.
Who is the manufacturer of CN7853?
OMEGA
