TRACO POWER TDN34822WI Dual Output DC-DC Converter
The TDN 3-4822WI from TracoPower is a 3W regulated dual output DC-DC converter housed in a compact DIP package. It features a 4:1 input voltage range from 18VDC to 75VDC, with fully regulated ±12VDC outputs capable of delivering up to 125mA each. The converter offers high efficiency of 82%, automatic recovery from short circuits, and a remote ON/OFF function. It includes built-in EN 55022 Class A filtering, and complies with EN 61000-4-2 ESD protection standards with a contact ±6kV and air ±8kV contact, meeting criteria A. The device has a 1600VDC I/O isolation voltage (60 seconds), over 1 Gigaohm isolation resistance, and a minimal 50pF I/O capacitance. Operating over a temperature range from -40°C to 70°C without derating, it is suitable for power management and industrial applications. The converter's dimensions are 9.1mm x 10.2mm x 13.2mm, and it features a non-conducting UL 94V-0 rated FR4 casing with silicone potting and tinned copper pins.
TRACO POWER TDN34822WI Dual Output DC-DC Converter Specifications:
- Input Voltage Range: 18VDC to 75VDC (4:1 ratio)
- Output Voltage: ±12VDC, up to 125mA per output
- Efficiency: 82%
- Isolation Voltage: 1600VDC (60 sec)
- Isolation Resistance: >1 GOhm
- Input Current: 40 mA typ. at no load
- Ripple and Noise: 50 mVp-p typ.
- Operating Temperature: -40°C to +70°C without derating
- Dimensions: 9.1 mm x 10.2 mm x 13.2 mm
- Enclosure: Non-conducting UL 94V-0 rated FR4, silicone potting, tinned copper pins
- Protection: Short circuit, EN 55022 Class A filtering, ESD contact ±6kV, air ±8kV
- Soldering Temperature: Max 260°C / 10 sec.
Buy the Traco Power TDN 3-4822WI – Reliable Dual Output DC-DC Converter for Industrial Applications
Upgrade your power electronics with the Traco Power TDN 3-4822WI, a 3-watt dual output DC-DC converter designed for industrial environments. This compact, highly efficient module features a wide input voltage range from 18V to 75V DC, providing robust ±12V outputs with up to 125mA each. It guarantees electrical isolation of 1600VDC, built-in filtering, and features protection against short circuits and electrostatic discharge in a small, durable case. Ideal for power management, automation, and industrial applications requiring reliable, high-performance voltage conversion. Buy online today to enhance your system’s performance with this dependable power solution.
Order your Traco Power Series TDN 3-4822WI today and give your power management systems the dependable quality they deserve for industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TDN34822WI?
You can click on the BUY or RFQ button to purchase TDN34822WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TDN34822WI?
You can download the TDN34822WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TDN34822WI?
TRACO POWER
