DELTA ELECTRONICS / FANS ASB0305LADR00 Brushless Cooling Fan
The DC fan is a brushless, high-efficiency cooling device designed for optimal airflow and low noise operation. It features a rated voltage of 5 VDC, with an operational range of 4.5 to 5.5 VDC, and an input current of approximately 0.10 to 0.17 A. The fan offers a maximum airflow of 0.091 m³/min at zero static pressure and a maximum speed of around 8,000 RPM, with low acoustical noise levels averaging 21 dB-A. Built with UL Class A insulation and a durable open-type external cover, it is rated for a lifespan of 20,000 hours and includes safety features such as lock rotor and polarity protection.
DELTA ELECTRONICS / FANS ASB0305LADR00 Brushless Cooling Fan Specifications:
- Rated Voltage: 5 VDC
- Operation Voltage Range: 4.5 - 5.5 VDC
- Minimum Start Voltage: 4.0 VDC
- Input Current: 0.10 (MAX. 0.17) A
- Input Power: 0.50 (MAX. 0.85) W
- Speed: 8000+15% RPM
- Max Air Flow: 0.091 (MIN. 0.077) m3/min or 3.21 (MIN. 2.73) CFM
- Max Air Pressure: 3.33 (MIN. 2.40) mmH2O or 0.131 (MIN. 0.094) inchH2O
- Acoustical Noise: 21.0 (MAX. 25.5) dB-A
- Insulation Type: UL Class A
- Insulation Strength: 10 Meg Ohm MIN. at 500 VDC
- Dielectric Strength: 5 mA MAX. at 500 VAC 50/60 Hz, one minute
- External Cover: Open Type
- Life Expectancy: 20,000 hours at 40°C, 65% RH
- Rotation: Counterclockwise from front view
- Lead Wires: UL 1061 AWG #28, Black (-), Red (+), Blue Signal
- Operating Temperature: -10 to +70°C
- Storage Temperature: -40 to +75°C
- Operating Humidity: 5% to 90% RH
- Storage Humidity: 5% to 95% RH
- Protection Features: Locked rotor protection, polarity protection
- Compliance: RoHS, UL 1061, UL 94V-0 plastic
- Certifications: UL Listed, Safe for industrial applications
Buy the Buy Delta DC Fan Part Number ASBO305LA-DRO0 Online
Experience reliable cooling with the Delta Brushless Cooling Fan, featuring a 5V DC operation, 8000 RPM speed, and a lifespan of 20,000 hours. Designed for optimal airflow and low noise, this fan is suitable for various electronic cooling applications. Made with UL Class A insulation and built to meet safety standards, it ensures durable and efficient performance in demanding environments. Easy to install, with polarity and lock rotor protection, this fan is the ideal choice for electronics cooling, ventilation, and industrial use. Shop now for fast online delivery.
Get Delta DC Fan ASBO305LA-DRO0 today—built for precision cooling and long-lasting durability.
Frequently Asked Questions
Where can I buy DELTA ELECTRONICS / FANS ASB0305LADR00?
You can click on the BUY or RFQ button to purchase ASB0305LADR00 from an authorized DELTA ELECTRONICS / FANS distributor.
How do I troubleshoot issues or seek technical support for part ASB0305LADR00?
You can download the ASB0305LADR00 datasheet or visit the DELTA ELECTRONICS / FANS website for support.
Who is the manufacturer of ASB0305LADR00?
DELTA ELECTRONICS / FANS
