DELTA ELECTRONICS / FANS ASB03512HBF00 Cooling Fan
The DC axial fan features a 12 VDC rated voltage, operating from 5.0 to 13.8 VDC, with a rated speed of 11,000 RPM. Designed with UL: Class A insulation and a sleeve bearing, it offers high airflow of up to 0.270 m³/min (9.507 CFM) and low acoustical noise averaging 37.0 dB(A). It withstands continuous operation for 30,000 hours at 40°C with 65% RH, and has dimensions complying with detailed drawings. Manufactured in China, it features a plastic frame and impeller, with a life span suited for various cooling applications.
DELTA ELECTRONICS / FANS ASB03512HBF00 Cooling Fan Specifications:
- Rated Voltage: 12 VDC
- Operation Voltage Range: 5.0 - 13.8 VDC
- Rated Speed: 11,000 RPM ±15%
- Max Air Flow: 0.270 m³/min (9.507 CFM)
- Min Air Flow: 0.230 m³/min (8.081 CFM)
- Static Pressure: 6.00 mmH2O (0.236 inchH2O)
- Sound Level: Max. 41.5 dB(A), Avg. 37.0 dB(A)
- Insulation: UL Class A
- Bearing Type: Sleeve Bearing
- Operating Temp: -10°C to +70°C
- Storage Temp: -40°C to +75°C
- Humidity (Operating): 5-90% RH
- Longevity: 30,000 hours at 40°C/65% RH
- Material: Plastic UL: 94V-0
- Lead Wire: UL 1061 AWG #26, color-coded (Red positive, Black negative, Blue frequency)
- Dimension Tolerance: ±0.3 mm
- Manufactured in China
- RoHS compliant
Buy the AELTA ASB03512HB – Reliable Cooling Fan for Industrial Applications
Purchase the AELTA cooling fan online now to ensure reliable airflow and long-lasting performance for your electronic cooling needs. With a 12 VDC operation, high airflow, UL insulation, and a lifespan of up to 30,000 hours, this fan is ideal for industrial and electronic cooling applications. Easy to install with detailed dimensions, it provides quiet operation at 37 dB(A) max, making it suitable for sensitive environments. Order today and upgrade your cooling system with confidence in quick delivery and quality assurance.
Order your AELTA Series ASB03512HB axial fan today and enhance your cooling solutions with dependable performance for industrial projects.
